Orvibo Smart Ultra-Thin Surface Mounted Magnetic Track Grille Light

Orvibo Smart Ultra-thin Surface-Mounted  Magnetic Track Grille Light

The blade ultra-thin smart magnetic track light integrates the four major technological innovations of "ultra-thin", "anti-glare", "intelligence" and "safety", and achieves extreme beauty in surface-mounted products; Achieved anti-glare eye protection; compatible with 10,000-level dimming and color adjustment and single-light intelligent control; only 6mm track magnetic suction + buckle safety guarantee

Product Specification of Orvibo Ultra-thin Grille Light

1. Power: 10w&12w&20w
2. Color rendering index: Ra>98
3. Color temperature range: 2700K~6000K
4. Beam angle: 24°
5. Communication method: Zigbee single lamp single control
6. Luminous flux: ≥600lm/720lm/1200lm
7. Size: 416*30*12mm/216*30*41mm/739*30*12mm
8. Photo mode: down-illumination
9. Material: aviation aluminum + PC
10. Control method: language, touch screen, scene opening, APP

Reserved plan
1. Reserve 220V power supply zero live wire;
2. The minimum clear space of the ceiling is not less than: 110mm
3. Hole size: φ75mm

Wiring scheme
1. Reserve 220V power supply zero live wire;
