Lutron RA2 Select Pico Wireless Shade Controls with Raise and Lower Remotely PM2-3BRL
Lutron Singapore Pico Wireless Controls The Pico wireless control is a flexible and easy to use device that allows the user to control Lutron wireless load control devices from anywhere in the...
Lutron Singapore Pico Wireless Controls
The Pico wireless control is a flexible and easy to use device that allows the user to control Lutron wireless load control devices from anywhere in the space. This battery operated control requires no external wiring.
Lutron RA2 Select Model Number
PM2-3BRL-TAW-S01：3 Button Raise and Lower Shade Arctic White
PM2-3BRL-TBL-S01：3 Button Raise and Lower Shade Black
Features of Lutron Singapore Pico Wireless Controls
• Utilizes Lutron reliable Clear Connect RF technology.
• Indicator LED flashes to indicate a button press or when unit is in programming mode.
• Easy reconfiguration for use as: – Handheld remote
– Wall mount control (with or without faceplate; faceplate adapter kit sold separately) – A table top control (table top pedestal sold separately).
• Battery powered Pico wireless control requires no wiring. • 10 year battery life (one CR2032 battery included). 1
• Control available in a variety of button marking options.
• Can provide control of blinds, curtains, or lighting devices within a range of 9 m through walls and 18 m line-of-sight.
• Provides control for the following (depending on model number):
– Vive2 systems, including:
· PowPak relay module
· PowPak CCO module
· PowPak 0–10 V- module
· EcoSystem module not available
– Energi Savr Node systems programmed with handheld App, through the use of a QS sensor module (QSM)
– PowPak modules
– GRAFIK Eye QS wireless systems
– Rania wireless controls
– HomeWorks QS wireless systems
– GRAFIK RA 2 systems
– Serena RF remote control shades
– Sivoia QS wireless systems
– Quantum systems3, through the use of a QS sensor module (QSM)
– myRoom prime and plus systems
NOTE: Not all systems are available in all regions
Specifications of Lutron Light Controls
Regulatory Approvals
- Lutron Quality Systems registered to ISO 9001:2015.
- PK2 (Europe) – CE Marked – TRA Certified
- PN2 (India) – WPC Certified
- PM2 (China) – imDA Certified
- PQ2 (Hong Kong) – RCM Compliant
- RoHS Compliant
Power
- Operating voltage 3 V-
- One (1) CR2032 battery (included)
System Communication and Capacity
- Pico wireless controls communicate using Radio Frequency (RF). See “Frequency/Channel Codes” in the Model Number section for more information.
- Unique system addresses prevent interference between systems.
- Pico wireless controls can be assigned to control shades or lighting devices that are within a range of 9 m through walls and 18 m line-of-sight.
Mounting Considerations
- All RF devices should be mounted on non-metallic surfaces to ensure proper performance.
- If you wish to mount your Pico wireless control to a metallic surface, the PICO-MOUNT-1-XX-CPN6774 will be required in order to maintain proper RF performance. For availability, please contact your local Lutron sales office.
Environment
- Ambient operating temperature: 0 ˚C to 60 ˚C
- Maximum 90%, non-condensing relative humidity
- Indoor use only
Warranty
1 Year Limited Warranty For additional Warranty information, visit www.lutron.com/TechnicalDocumentLibrary/ 369-119_Wallbox_Warranty.pdf
